The secret of preventing the side turn of the pump truck

The tilt device for measuring the vehicle's level and the sensor for measuring the pressure on the supporting leg.The tilt sensor can sense the vehicle's level and send real-time horizontal Angle information, which can effectively avoid the tilting caused by ground slow decline.The function of the tilt sensor is to measure the tilt Angle of the vehicle in real time.The measurement accuracy of the tilt sensor is higher than 0.05 degrees.It can filter out small tremors caused by engine and pump tremors and trigger alarm when the Angle of left and right is greater than 3 degrees or the Angle of front and rear is greater than 5 degrees.

2. Force sensor of the supporting leg detects the pressure of each supporting leg in real time. When the pressure of two supporting legs of one side is less than a certain value, it timely make a warning or terminates the current action.What needs to be added is that artificial intelligence is never omnipotent. This kind of axial gravity sensor can only sense the pressure situation in a certain direction. Due to the different vertical degree of the whole vehicle and the supporting legs when pumping, the authenticity of the force condition detected is not enough. There is a possibility of false or missing signals.

3. There are many factors causing the dump of the pump truck. In addition to necessary protective measures, it is particularly important to make human judgment and on-site experience of operators.A good operator is better than any intelligent device.The following faults are more likely to occur, which can only be avoided according to the operator's experience.

1. Soft ground

2. Hollow ground

3. Field work

4. Don't be careless on the edge field

5.Avoid dangerous road conditions

Iv. Correct placing range: there are four types of placing for the pump truck: full placing mode, front placing mode, left placing mode and right placing mode.To enhance the vehicle safety factor, prevent the rear vehicle tilt when placing, when the boom to the rear bodywork placing, boom Angle and the center line of the car + / - 12.5 ° not allowed within the scope of placing, two boom level restrictions prohibit cloth distance is 6501 mm.
